WL108

The WL108 Wheel Load Scale is a portable, low-profile device designed for fast and accurate measurement of wheel loads, and through them, axle loads and the total weight of vehicles using pneumatic tire wheels. This device is extremely useful for vehicle owners and maintenance personnel as it allows for precise measurement of wheel loads, which is necessary for proper load distribution and overall vehicle function.

The WL108 Wheel Load Scale is easy to use and is great for use in a variety of situations, from vehicle maintenance and servicing to setting load distribution on trucks and other heavy vehicles. This device is made of high-quality materials and has a durable design that allows for long-term use without the need for maintenance.

If you want a precise and reliable way to measure wheel loads, the WL108 Wheel Load Scale is an excellent option for you. This scale is fast, accurate, and easily portable, making it ideal for use in a variety of situations and environments

Load
0 – 2 t
0 – 3 t
0 – 10 t
0 – 15 t
Division weighing (standard/smaller*)
 10 / 5* kg
10 kg
50 / 20* kg
50 kg
Accuracy class
OIML R-76, Accuracy Class IIII
Operating temperature range
-20°C do +60°C
Construction Corrosion-resistant aluminum alloy, IP 65
Display LCD, 24 mm, graphic, with backlight
Power supply Integrated rechargeable power source, for 180 hours of operation.
Charging (and operation) via 12V battery or AC adapter.
Platform height
19 mm
19 mm
17 mm 17 mm
Weight
13.5 kg
13.5 kg
16.5 kg
Dimensions
see the sketch
Connection Cable, Wireless (option)
Documentation
