DESCRIPTION

The ring-shaped protective chamber is standard only for models with a load receiver dimension of ØxV 90x40 mm.

TECHNICAL SPECIFICATIONS

• LCD display with backlight, digit height 15 mm
• Load receiver dimensions (stainless steel*): 81 mm ,105 mm* ,130x130 mm* ,150x170 mm*,
• Additional batteries not included. AUTO-OFF function for battery conservation
• Total dimension (without chamber) WxDxH 165x230x80 mm
• Net weight approx. 1 kg
• Permitted temperature range 5 ° C / 35 ° C

Note: Data in the header: the free application KERN SHM-01 can be used for printing 4 lines in the header for the printer 911-013 and YKB-01N. : Complete version of the application

Model	Division showing d g	Load Max g	Repeatability   g	Linearity     g	Min. mass of pieces. g/piece	Receiver loads mm	OPTION
								DKD Certificate
440-21 A	0,001	60	0,001	± 0,003	0,002	Ø81		963-127
440-33 N	0,01	200	0,01	± 0,02	0,02	Ø105		963-127
440-35 N	0,01	400	0,01	± 0,03	0,02	Ø105		963-127
440-35 A	0,01	600	0,01	± 0,03	0,02	Ø105		963-127
440-43 N	0,1	400	0,1	± 0,2	0,2	130x130		963-127
440-45 N	0,1	1000	0,1	± 0,2	0,2	130x130		963-127
440-47 N	0,1	2000	0,1	± 0,2	0,2	130x130		963-127
440-49 N	0,1	4000	0,1	± 0,3	0,2	150x170		963-127
440-49 A	0,1	6000	0,1	± 0,3	0,2	150x170		963-127
440-51 N	1	4000	1	± 2	2	150x170		963-127
440-53 N	1	6000	1	± 2	2	150x170		963-128
